Features
SENSOR DRY SYSTEM
Measures moisture in the drum during the cycle, then automatically adjusts the drying time and temperature for optimal fabric care.
SMARTDIAGNOSIS™
If you ever experience an issue with your Lg dryer, you have to worry. The SmartDiagnosis™ feature helps the service center diagnose problems over the phone, or with a simple app on your smart phone, helping you minimize costly, inconvenient service calls.
SMARTTHINQ® TECHNOLOGY
Expand the limits of your laundry room with the LG SmartThinQ® app. Select a cycle, start or stop the wash and get notifications about when your laundry will be done, all from your smartphone. It even works with the Google Assistant and Amazon Alexa, so you can manage your laundry with simple voice commands.
ENERGY STAR® QUALIFIED
Among the most energy-efficient dryers in its class.
STEAM SANITARY™
Wash the unwashable. Steam safely sanitizes items marked as non-washable. Give favorite clothes new life in just 10 minutes. TurboSteam™ technology helps refresh fabrics and reduce wrinkles in half the time of other steam settings. (Based on tests conducted at the LG test lab facility on 12/10/2014)
STEAMFRESH™ CYCLE
The SteamFresh™ Cycle refreshes, and reduces wrinkles in up to five garments at a time with one 20-minute dryer cycle.
TURBOSTEAM™ TECHNOLOGY
LG TurboSteam™ technology to the rescue. Toss the shirt in the dryer, turn on TurboSteam™ and in just 10 minutes your shirt is back in tip-top shape. Also helps refresh fabrics and reduce wrinkles in half the time of other Steam settings.
KEEP CLOTHES WRINKLE FREE
Always forgetting to remove your laundry? No problem. Choosing the Wrinkle Care option periodically tumbles your laundry to keep clothes wrinkle-free.
FLOWSENSE® DUCT CLOGGING AND LINT FILTER INDICATORS
With newly installed dryers, LG highly recommends getting your exhaust venting duct cleaned out. Even if your old dryer was working fine, LG dryers are built to detect vent blockage. This is a safety feature measure because vent blockage can prevent your dryer from properly drying and even cause some serious bodily injuries, clothes scorching, or fire hazards.
NEVERUST® STAINLESS STEEL DRUM
This stainless steel drum is designed to last for many, many years without rust. Longevity allows for many large loads over the course of many years!
Specifications
General
Type
Vented
Power Source
Gas
Color
Grey
Manufacturer Color
Graphite Steel
Tub Material
Stainless Steel
Capacity
Capacity
7.4 cu. ft.
Cycle Information
Number of Cycles
23
Dry Cycles
• Normal
• AI Dry
• Bedding
• Delicates
• Towels
• Quick Dry
• Timed Dry
• Power Dry
• Perm. Press
• SteamFresh™
• Heavy Duty
• Air Dry
• Steam Sanitary™
• Super Dry
• Active Wear
• Jeans
• Blanket Refresh
• Low Temp Dry
• Overnight Dry
• Easy Ironing
• Small Load
• Large Load Dry
• X Large Load Dry
• AI Dry
• Bedding
• Delicates
• Towels
• Quick Dry
• Timed Dry
• Power Dry
• Perm. Press
• SteamFresh™
• Heavy Duty
• Air Dry
• Steam Sanitary™
• Super Dry
• Active Wear
• Jeans
• Blanket Refresh
• Low Temp Dry
• Overnight Dry
• Easy Ironing
• Small Load
• Large Load Dry
• X Large Load Dry
Options
• Cycle Optimization
• Damp Dry Signal
• Wrinkle Care
• Control Lock
• Wi-Fi
• Energy Saver
• TurboSteam®
• Reduce Static
• Remote Start
• Drum Light Signal
• Cycle Edit List
• Damp Dry Signal
• Wrinkle Care
• Control Lock
• Wi-Fi
• Energy Saver
• TurboSteam®
• Reduce Static
• Remote Start
• Drum Light Signal
• Cycle Edit List
Features
Technologies
• AI Sensor Dry
• Manual Dry Steam Technology: LG TurboSteam®, LG StreamFresh®, SteamSanitary®
• Smart WiFi Enabled ThinQ® Technology with ThinQ Care
• Remote Start and Cycle Monitor
• Energy Monitoring
• LG Smart Diagnosis Dryer
• FlowSense® Duct Clogging Indicator
• Dryer Full Lint Filter Indicators
• Dial-A-Cycle
• NeveRust® Stainless Steel Drum
• Manual Dry Steam Technology: LG TurboSteam®, LG StreamFresh®, SteamSanitary®
• Smart WiFi Enabled ThinQ® Technology with ThinQ Care
• Remote Start and Cycle Monitor
• Energy Monitoring
• LG Smart Diagnosis Dryer
• FlowSense® Duct Clogging Indicator
• Dryer Full Lint Filter Indicators
• Dial-A-Cycle
• NeveRust® Stainless Steel Drum
Dryness Levels
• Very Dry
• More Dry
• Normal Dry
• Less Dry
• Damp Dry
• More Dry
• Normal Dry
• Less Dry
• Damp Dry
Temperature Settings
• High
• Med. High
• Medium
• Low
• Ultra Low
• Med. High
• Medium
• Low
• Ultra Low
Number of Temperature Settings
5
Wi-Fi
Yes
Steam Cycle
Yes
Control Lock
Yes
Light
Yes
Reversible Door
Yes
Sensor Dry
Yes
Stackable
Yes
Additional Information
• LCD Display
• Manual Dry Times: 10 min ~ 100 min (10 min increments)
• Precise Temperature Control with Variable Heater
• 3-Minute Installation Check
• End of Cycle Signal
• Drum Light (Door Open)
• Venting Option: 3-Way Venting
• 4 Adjustable Legs
• Remaining Time Display / Status Indicator(s)
• Cabinet: Painted Steel
• Door: Tempered Glass Door
• Manual Dry Times: 10 min ~ 100 min (10 min increments)
• Precise Temperature Control with Variable Heater
• 3-Minute Installation Check
• End of Cycle Signal
• Drum Light (Door Open)
• Venting Option: 3-Way Venting
• 4 Adjustable Legs
• Remaining Time Display / Status Indicator(s)
• Cabinet: Painted Steel
• Door: Tempered Glass Door
Electrical Information
Information
• 120V
• 60Hz
• 11.5A
• BTU Rating: 20,000
• 60Hz
• 11.5A
• BTU Rating: 20,000
Certifications and Approvals
Energy Star Certified
Yes
Additional Information
CSA Listed
Accessories
Optional
• LP Conversion Kit: 383EEL3002D
• Side Venting Kit: 3911EZ9131X
• Drying Rack: 3750EL1001A
• Pedestal: WDP6V
• Side Venting Kit: 3911EZ9131X
• Drying Rack: 3750EL1001A
• Pedestal: WDP6V
Dimensions
Class Width
26" - 27"
Width
27 inch(es) / 68.58 cm
Height
39 inch(es) / 99.06 cm
Depth
29.75 inch(es) / 75.57 cm
Weight
136 lb(s) / 61.69 kg
Additional Dimensions
Depth with Door Open: 51 3/8"
Shipping Dimensions
Width
28.88 inch(es) / 73.36 cm
Height
46.5 inch(es) / 118.11 cm
Depth
31.38 inch(es) / 79.71 cm
Weight
146.61 lb(s) / 66.5 kg
Warranty
Warranty
• Parts and Labor: 1 Year
• Drum: 3 Years
• Drum: 3 Years
UPC
UPC#
195174048894
