Features
ACT™ CONTROL TECHNOLOGY
Airflow Control Technology (ACT) allows the installer to set the maximum fan CFM to align with local codes and regulations.
Additional Features
ICON TOUCH™ CONTROLS
Seamlessly integrates into the hood’s stainless steel canopy and allows users to easily control the 5-speeds, delay-off function, auto reminders and Airflow Control Technology.
Specifications
General
Series Name
Core Siena
Blower Included
Yes
Airflow
650 CFM
Style
Chimney
Color
Stainless Steel
Installation
Wall Mount
Features
Technologies
• ICON Touch® Controls
• ACT™ Technology
• TruHue™
• ACT™ Technology
• TruHue™
Ducting Information
• Vertical Internal Blower: 8" Round
• Horizontal Internal Blower: 8" Round or 3-1/4 x 10"
• Horizontal Internal Blower: 8" Round or 3-1/4 x 10"
Speeds
• Speed Levels: 5*
• Blower CFM (Min. - Max.): 200 - 650
• Sones (Min. - Max.): 1 - 6
• ACT 390 CFM (Min. - Max.): 200 - 390
• ACT 290 CFM (Min. - Max.): 200 - 290
• *When ACT™ is enabled the maximum speed levels will change. ACT 390 CFM = 4 speeds and ACT 290 CFM = 3 speeds
• Blower CFM (Min. - Max.): 200 - 650
• Sones (Min. - Max.): 1 - 6
• ACT 390 CFM (Min. - Max.): 200 - 390
• ACT 290 CFM (Min. - Max.): 200 - 290
• *When ACT™ is enabled the maximum speed levels will change. ACT 390 CFM = 4 speeds and ACT 290 CFM = 3 speeds
Additional Information
• Auto Delay-Off
• Lighting: LumiLight LED with TruHue™, 6W x2
• Dual-Level Lighting
• Filters: Hybrid Baffle x2
• Recirculating Option
• Extension Duct Cover Option: Up to 12' Ceiling
• Lighting: LumiLight LED with TruHue™, 6W x2
• Dual-Level Lighting
• Filters: Hybrid Baffle x2
• Recirculating Option
• Extension Duct Cover Option: Up to 12' Ceiling
Electrical Information
Information
• 120 V
• 4 A
• 60 Hz
• 4 A
• 60 Hz
Certifications and Approvals
Information
ADA Compliant with remote accessory
Accessories
Optional
• ZRC-00SI Recirculating Kit (w/ charcoal filters)
• Z1C-00SI Extension Duct Cover, (For up to a 12' ceiling)
• MUA008A Make-Up Air Damper
• AK1716 Stainless Steel Telescopic Backsplash
• RC-0002 Wireless Remote Control Kit
• Z1C-00SI Extension Duct Cover, (For up to a 12' ceiling)
• MUA008A Make-Up Air Damper
• AK1716 Stainless Steel Telescopic Backsplash
• RC-0002 Wireless Remote Control Kit
Dimensions
Class Width
36"
Width
35.87 inch(es) / 91.12 cm
Height
12.37 inch(es) / 31.43 cm
Depth
21.94 inch(es) / 55.72 cm
Warranty
Warranty
3 years parts, 1 year labor
