Features
DEEP-WATER WASH SYSTEM
• Provides optimal wash performance with deep-water wash and rinse cycle options and vigorous cleaning action
• Traditional flex-vane agitator provides four distinct wash profiles — from aggressive to gentle — designed to pull clothes from the top to the bottom of the wash basket
• PowerWash® cycle provides more agitation, hotter water, and an extra rinse for the dirtiest loads
• Traditional flex-vane agitator provides four distinct wash profiles — from aggressive to gentle — designed to pull clothes from the top to the bottom of the wash basket
• PowerWash® cycle provides more agitation, hotter water, and an extra rinse for the dirtiest loads
TRADITIONAL FLEX-VANE AGITATOR
Provides four distinct wash profiles—from aggressive to gentle—designed to pull clothes from the top to the bottom of the wash basket.
BUILT TO LAST (MAT23)
• Heavy-duty front panel — robust and easy to remove
• Front-panel accessibility — provides fast entry to the motor, transmission, and wash tub for streamlined self-service
• Built-in, easy-to-use diagnostics — help servicers identify problems quickly
• Watertight, flexible, triple-lip seal — helps keep moisture safely away from the shaft and protects the premium bearings
• Front-panel accessibility — provides fast entry to the motor, transmission, and wash tub for streamlined self-service
• Built-in, easy-to-use diagnostics — help servicers identify problems quickly
• Watertight, flexible, triple-lip seal — helps keep moisture safely away from the shaft and protects the premium bearings
Additional Features
CONTROLS TO MEET YOUR NEEDS (MAT23CS and MAT23MN)
Mechanical controls provide a simple user interface with robust, easy-to-use knobs (MAT23CS and MAT23MN)
Specifications
General
Capacity
25 lb
Cylinder Volume
2.9 Cu. Ft.
Motor
1/2 hp
Maximum Speed
700 rpm
G-Force
144 g
Color
White
Manufacturer Color
White
Features
Additional Information
• Operating Pressure — psi (bar): 20–100 (1-8)
• Inlet Hose Length — ft (m): 6 (1.8)
• Drain Hose Length — ft (m): 4 (1.3)
• Mechanical Controls
• Built-in Easy-to-Use Diagnostics
• Traditional Flex-Vane Agitator
• Deep-Water Wash System
• Inlet Hose Length — ft (m): 6 (1.8)
• Drain Hose Length — ft (m): 4 (1.3)
• Mechanical Controls
• Built-in Easy-to-Use Diagnostics
• Traditional Flex-Vane Agitator
• Deep-Water Wash System
Electrical Information
Information
• 120 V
• 60 Hz
• 15 A
• 60 Hz
• 15 A
Dimensions
Width
27 inch(es) / 68.58 cm
Height
42.5 inch(es) / 107.95 cm
Depth
26 inch(es) / 66.04 cm
Weight
145 lb(s) / 65.77 kg
Additional Dimensions
Lid Opening: 17"
Shipping Dimensions
Width
29 inch(es) / 73.66 cm
Height
49 inch(es) / 124.46 cm
Depth
27.5 inch(es) / 69.85 cm
Weight
163.01 lb(s) / 73.94 kg
Warranty
Warranty
Limited 5 Years Parts Only
