Features
FLEX ZONE™
Flex Zone™ is a large open area that offers greater flexibility for cookign multiple dishes at one time. Easily accommodates various cookware sizes.
PAUSE
Function, pauses cooking and re-starts at the same temperature with a simple command.
VIRTUAL FLAME™
Vertual Flame™ is a beautiful and intuitive LED light that displays virtual flames to provide an attractive visual cue when the heat is on.
POWER BOOST
Brings large quantities of food to cooking temperature faster by increasing the induction elemente power.
WI-FI-ENABLED SEVEN-INCH LCD CONTROL PANEL
The touch interface serves as your culinary command center, allowing you to effortlessly swipe through cooking functions, access pre-programmed settings and follow step-by-step recipes.
Specifications
General
Series Name
Modernist
Color
Black
Manufacturer Color
Black
Fuel Type
Electric Induction
Cooktop
Burners/Elements
6
Power Output
• Flex Zone Left Front: 1800W / 2600W (B)
• Flex Zone Left Rear: 1800W / 2600W (B)
• Power Coil Center: 3600W / 4800W (B)
• Flex Zone Right Rear: 1400W / 1800W (B)
• Flex Zone Power: 3300W / 3600W (B)
• Flex Zone Left Rear: 1800W / 2600W (B)
• Power Coil Center: 3600W / 4800W (B)
• Flex Zone Right Rear: 1400W / 1800W (B)
• Flex Zone Power: 3300W / 3600W (B)
Burner/Element Size
• Flex Zone Left: 7 19/20"W x 15 6/25"D
• Flex Zone Right: 7 19/20"W x 15 6/25"D
• Center Heating Element: 7"/11" Power Coil™ (VF)
• Right Rear Heating Element: 6" Power Coil™ (VF)
• Flex Zone Right: 7 19/20"W x 15 6/25"D
• Center Heating Element: 7"/11" Power Coil™ (VF)
• Right Rear Heating Element: 6" Power Coil™ (VF)
Elements
Smoothtop
Features
Technologies
• Wi Fi Connect
• Flex Zone™
• Virtual Flame™
• Dacor iQ Kitchen App
• Flex Zone™
• Virtual Flame™
• Dacor iQ Kitchen App
Wi-Fi
Yes
Clock
Yes
Control Lock
Yes
Digital Display
Yes
Downdraft Ventilation
No
Additional Information
• 7" LCD Control Panel with Guided Cooking
• Guided Cooking: 15 Ea
• Recommended Power Level
• Pause
• Power Level Setting 9 + Power Boost
• Quick Stop
• Simmer/Melt
• Power On/Off
• Auto Pan Detection
• Sound On/Off
• Demo Mode
• Bluetooth Connect
• Hood Connectivity On/Off
• Virtual Flame On/Off
• 5 Zones with Booster
• Guided Cooking: 15 Ea
• Recommended Power Level
• Pause
• Power Level Setting 9 + Power Boost
• Quick Stop
• Simmer/Melt
• Power On/Off
• Auto Pan Detection
• Sound On/Off
• Demo Mode
• Bluetooth Connect
• Hood Connectivity On/Off
• Virtual Flame On/Off
• 5 Zones with Booster
Electrical Information
Information
• 10.8 kW / 9.5 kW
• 240 V / 208 V
• 60 Hz
• 40 A
• 240 V / 208 V
• 60 Hz
• 40 A
Dimensions
Class Width
30"
Width
30 inch(es) / 76.2 cm
Height
3.98 inch(es) / 10.1 cm
Depth
21.26 inch(es) / 54.0 cm
Additional Dimensions
For more information refer to dimension manual
Warranty
Warranty
Limited 1 year parts and labor
UPC
UPC#
847364019473
