Specifications
General
Color
Black
Manufacturer Color
Black
Fuel Type
Electric Induction
Type
Built-In
Cooktop
Burners/Elements
4
Power Output
• Front Left Element (Standard / Boost): 2,100 W / 3,700 W
• Rear Left Element (Standard / Max. Boost): 2,100 W / 3,700 W
• Right Element (Standard / Max. Boost): 2,300 W / 3,700 W
• Rear Right Element (Standard / Max. Boost): 2,600 W / 3,700 W
• Rear Left Element (Standard / Max. Boost): 2,100 W / 3,700 W
• Right Element (Standard / Max. Boost): 2,300 W / 3,700 W
• Rear Right Element (Standard / Max. Boost): 2,600 W / 3,700 W
Burner/Element Size
• Front Left Element: 7" x 7 7/8"
• Rear Left Element: 7" x 7 7/8"
• Right Element: 9"
• Rear Right Element: 11"
• Rear Left Element: 7" x 7 7/8"
• Right Element: 9"
• Rear Right Element: 11"
Elements
Smoothtop
Features
Technologies
Induction Technology
Control Lock
Yes
Digital Display
Yes
Additional Information
• Frameless Black Glass
• Slide Touch Control with Independent Zone Timers
• Precise temperature control with 9 cooking levels
• Power boost for reaching the highest temperature quickly and efficiently
• Digital Display for Power Level Indication Yes
• Timer Display
• Boost Function
• Bridge Function
• Keep Warm Function
• Automatic Pan Detection
• Residual Heat Indicators
• Display Lock
• Slide Touch Control with Independent Zone Timers
• Precise temperature control with 9 cooking levels
• Power boost for reaching the highest temperature quickly and efficiently
• Digital Display for Power Level Indication Yes
• Timer Display
• Boost Function
• Bridge Function
• Keep Warm Function
• Automatic Pan Detection
• Residual Heat Indicators
• Display Lock
Electrical Information
Information
• Total Power Consumption: 7,400 W
• 240/208 V
• 60 Hz
• 40 A
• Electrical Connection: Flexible Conduit, 3-Wire or 4-Wire
• 240/208 V
• 60 Hz
• 40 A
• Electrical Connection: Flexible Conduit, 3-Wire or 4-Wire
Dimensions
Class Width
30"
Width
30.71 inch(es) / 78.0 cm
Height
2.37 inch(es) / 6.03 cm
Depth
20.43 inch(es) / 51.9 cm
Weight
22.05 lb(s) / 10 kg
Additional Dimensions
Required Cutout Size (W x D) (in): 29 1/2 x 19 5/16
